Parameters
Applicable to: calcination of LFP
Maximum temperature: 900 ℃
Furnace cavity dimenison: W2280×H420×L80000mm, Lmax=100m
Furnace atmosphere: N2
Gas-Electric Hybrid Heating - the heating section uses natural gas radiant tubes for heating, and the insulation section uses electric heating, which saves power and achieves temperature uniformity as well;
Optimized Structure - front arch and rear flat structure, smooth gas/glue exhaust, good temperature uniformity, and low energy consumption;
Excellent Sealing Performance - multiple sealing structures ensure stable pressure in the furnace;
Uniform Temperature - high accuracy of temperature control, auxiliary heating, and cross-sectional temperature uniformity of the insulation section (within ±6℃);
Significant Cooling Effect - various cooling methods such as air cooling and water cooling with significant effects;
Thermal Insulation and Energy Saving - Multi-layer, high-quality and environmentally-friendly thermal insulation materials are used to reduce heat loss and save energy consumption;
Low Power Consumption and Low Air Usage – Optimized equipment structure and temperature control program, and the power consumption and air usage are at the lowest level in the industry.
